SOLD Used 6 Head Moulder with Auto Tool Setting - Weinig Unimat Gold



SOLD Used Weinig Moulder - Model: Unimat Gold with Auto Tool Setting System
Year: 2004

This used 6 head moulder manufactured by Weinig features an 8.2 ft. infeed straightening table with powered table roller.

Technical Specifications:

  • ATS system for motorized setting of the outside vertical and both top heads from the memory controls
  • Up to 500 profile settings can be stored and recalled from memory
  • Spindle diameter of 1 1/2” with a head configuration of bottom (10 HP) Right (10 HP) Left (10HP)
  • Top #1 (15 HP)
  • Top #2 (20 HP)
  • 5.5 HP inverter controlled feed with speeds of 20-98 FPM
  • electronic brakes on all spindles running at 6000 RPM.
  • Chromed table plates
  • 8.2 foot long infeed straightening table with powered table roller in the outfeed section
  • Receding chipbreaker on both top heads as well as pressure elements equipped with digital RO’s and a cutting circle of 7 7/8”

  • Manual waxilit pump and central lubrication included.

Note: Does not include cutter heads

Contact us today
Phone 678.642.9722
