Used Brandt Automatic Edge Bader - Model KD-78CFU



Used Brandt Model KD-78CF Automatic Edge Bander
Serial Number: 0-261-02-7046

This used automatic edgebander manufactured by Brandit has a working capacity of 0.016" to 1/2" edgeband thickness; 1/2" to 2-3/8" edgeband height and panel thickness 5/16" minimum and 2-3/16" maximum.  And it comes equipped with all related equipment.

Technical Specifications:

  • PC-16 program control with color LCD screen and 8 MB RAM
  • digital height indicator
  • ntegrated electronic line control
  • joint trimming unit with two 3 HP motors (one clockwise and one counterclockwise)
  • diamond cutterheads
  • universal automatic magazine for strip and coil feeding with an 800mm diameter table

  • one large driven pressure roller with pneumatic pressure control and three secondary rollers with controlled side pressure setting of pressure zone with digital counter; with a strengthened pre-cutter for cutting thick PVC edge from the coil (maximum e x 45mm)
  • Quickmelt gluing system with large granulate hopper and auto feed system with a pre-melting unit between the hopper and glue roller
  • quick-change tank with LED thermostat and infrared radiant glue heat zone control
  • #310 end trimming unit with two 0.35kw motors
  • electronic brakes for straight or chamfer with program controlled indexing from straight to bevel end trimming
  • #4131 fine trimming unit with two 0.55kw motors with electronic brakes and horizontal and vertical tracing wheels tiltable from 0 to 25 degree
  • indexing via digital "Quickset Systems" and program controlled indexing
  • contour trimming unit for front and trailing corners
  • two 0.3kw motors
  • electronic brakes
  • scraping unit with programmed controlled indexing
  • top and bottom buffing unit with two 2 800 R.P.M
  • polishing motors; with a sound and safety enclosure
  • electrics wired for AC 3/60/230 volt operation

For more information...

Phone 678.642.9722
