SOLD Used Balestrini Twin Table Mortisor - Model: Micron
This twin table mortisor manufactured by Balestrini features a 500 to 800 hourly slot production.
Technical Specifications:
- (1) spindle per side Spindle has variable speed on oscillation stroke
- Tables have air over oil variable speed feed rate
- (1) pneumatic hold down clamp per table
- 3 HP spindle motor producing a spindle speed of 9 000 RPM
- 1 HP oscillation motor
- Oscillating speeds of 120 to 240 strokes per minute
- Max. length of stroke: 120 mm
- Max. depth of mortise: 80 mm
- Max. Bit diameter: 30 mm
- Tables tilt left or right 20 degrees
- Hourly production is 500 to 800 slots
